Pro3000™ Analog Tone and Probe

Pro3000 Analog Tone & Probe Kit tones and traces wire.
  • Tone and trace wire on non-active networks
  • SmartToneTM technology provides five distinct tones for exact pair identification
  • Sends loud tone up to 10 miles (16 kilometers) on most cables
  • Loud speaker on Probe makes the tone easier to hear through drywall, wood, and other enclosures
  • Angled bed-of-nails clips allow easy access to individual pairs
  • RJ-11 connector is ideal for use on telephone jacks
  • Attach nylon pouch (included in kit) to your belt for easy transport
Talk to an Expert Where to Buy



Overview

The Pro3000 Analog Tone and Probe is your best choice for toning and tracing wire on non-active networks, and specifi­cally for identifying individual pairs with SmartTone® technology.

Angled bed-of-nails clips allow easy access to individual wires, and the RJ-11 connector is ideal for use on telephone jacks. The large loud speaker on the network probe allows you to hear through drywall, wood or other enclosures to find wires quickly and easily.

You can send this loud tone up to 10 miles (16 kilometers) on most cables! Attach the nylon pouch to your belt, and you will be equipped for any wire identification job.



Features

Pro3000 Capability

Use the SmartTone capability of the Pro3000 Analog Tone Generator to identify the right pair. When touching the wires together and momentarily shorting the far end of a cable pair, the SmartTone technology will change the cadence of the tone generated. This tone change you hear through the probe positively verifies the correct wire pair. SmartTone provides five distinct tones for exact pair identification.



Tone Generator features:

  • SmartTone technology
  • Send tone signal up to 10 miles on most cables
  • Line cord features angled bed-of-nails clips and ruggedized RJ-11 plug for direct access to phone and data jacks without adapters
  • External switch allows selection of solid or alternating tone options, indi­cated with solid or flashing LEDs
  • Continuity testing
  • Line polarity confirmation
Pro3000 Design

The Pro3000’s ergonomic sleek design is easy to handle and use. The large speaker on the probe makes the tone easier to hear through walls, enclosures, wood or plaster. A recessed on/off button helps prevent the probe from accidentally being turned on in the pouch. It accommodates a headset (sold separately) for use in noisy environments.

Probe features:

  • Loud large speaker amplifies tone through walls, enclosure, wood or plaster
  • Easy-to-use adjustable volume control dial
  • “Quick-twist” tip for easy replacement
  • Free spare tip inside Pro3000 Tone and Probe Kit



Models & Accessories


Models
Model Number/Name Description
26000900
Pro3000 Analog Tone & Probe Kit
26100900
Pro3000 Analog Probe
26200900
Pro3000 Analog Tone Generator

Accessories
Model Number/Name Description
26100103
Pro3000 Analog Probe replacement tip (two per bag)


Specifications

Pro3000 Analog Toner Specifications

User interface

Slide switch selects Continuity or Tone Mode

Push button switch selects SOLID, ALT or OFF

Tone mode LED

Continuity/Polarity LED

Solid Frequency

1000 Hz nominal

Alternating Frequency

1000/1500 Hz nominal

Over Voltage Protection

60 Vdc in Toner/Polarity Mode

Output Power in Tone Mode

8 dbm into 600 ohms

Output Voltage Level in Continuity Mode

8 Vdc with fresh battery

Battery

9V alkaline

Temperature

Operating: -20° C to 60° C, Storage: -40° C to 70° C

Case dimensions

2.7 in. x 2.4 in. x 1.4 in. (6.9 cm x 6.1 cm x 3.6 cm)



Pro3000 Analog Probe Specifications

User interface

ON/OFF push button

Volume dial

Replaceable tip

3.5 mm earphone jack

Battery

9V alkaline

Temperature

Operating: -20° C to 60° C, Storage: -40° C to 70° C

Case dimensions

9.8 in. x 1.6 in. x 1.3 in. (24.9 cm x 4.1 cm x 3.3 cm)
